Fluke 5502A Multi-Product Calibrator with Option SC600 - CALIBRATED WITH FULL TEST DATA!

You are bidding on a Fluke 5502A Multi-Product Calibrator with Option SC600 Installed. It will arrive with a fresh calibration with full pre and post test data performed by an ISO 17025 accredited lab. The calibration/alignment alone costs over $2000 USD!  The Fluke 5502A-SC600 has a list price from Fluke of 56K.

The Fluke 5502A Multi-Product Calibrator addresses common workload items like 3.5 and 4.5 digit digital multimeters and more. It comes with internal and external protection features that enable you to transport it easily and perform onsite or mobile calibration. The 5502A can also be fully automated with MET/CAL® Plus Calibration Management Software. It is the ideal calibrator for metrology professionals who need a solution for calibrating low-to-medium accuracy electrical instrumentation.

The Fluke 5502A Calibrator sources direct voltage and current, alternating voltage and current with multiple waveforms and harmonics, simultaneous voltage outputs or dual voltage and current to simulate dc and ac power with phase control, resistance, capacitance, thermocouples and RTDs. The 5502A can also measure thermocouples and thermocouple simulators. Two options add the capability to calibrate oscilloscopes to either 300 MHz or 600 MHz. Additionally, with the 52120A Transconductance Amplifier and current coils, the 5502A can calibrate instruments at up to 6000A.

Features of the Fluke 5502A include:

• Calibrates a wide variety of electrical test equipment
• Robust protection circuits prevent costly damage from operator error
• Ergonomically designed carrying handles make the 5502A easy to transport
• Rugged carrying case with built-in handles and wheels and removable front/rear access doors for in-situ calibration in almost any environment
• Current output that extends to 120 A when paired with the 52120A Transconductance Amplifier

Specifications of the Fluke 5502A include:

• Direct volts: 0 to ± 1020 V
• Direct current: 0 to 20.5 A
• Alternating volts: 1 mV to 1020 V / 10 Hz to 500 kHz
• Volt*Hertz: 1000 V@ 10 kHz/330 V@100 kHz
• Alternating current: 29 μA to 20.5 A / 10 Hz to 30 kHz
• Waveforms: Sine, square, triangle, truncated sine
• Resistance: 0 Ω to 1100 MΩ
• Capacitance: 220 pF to 110 mF
• Power (phantom loads): 20.9 kW
• Phase control: 0.01°
• Thermocouple (source and measure temperature): B, C, E, J, K L N R, S, T, U / 10 μV/°C and 1 mV/degC
• RTD (source temperature): Pt 385-100 Ω, Pt 3926-100 Ω Pt 3916-100 Ω, Pt 385-200 Ω, Pt 385-500 Ω, Pt385 1000 Ω, PtNi 385-120 Ω, (Ni120), Cu 427 10 Ω
• Interfaces: RS-232, IEEE 488
• Frequency uncertainty:
• Oscilloscope calibrator (optional): Levelled sine wave from 5 mV to 5.5 Vpp max, frequencies 50 kHz to 600 kHzz; edge rise times of < 300ps, multiple trigger functions, lowest dc, square wave and timing uncertainty
• Current boost transconductance amplifier: 0 to 100 A dc, 0 to 120 A ac, dc to 10 kHz, up to 6000 A with accessory current coils

This unit is in excellent condition, has been fully tested and is guaranteed functional. It comes with a 30 day right of return should it not perform to your expectations. Please review pics and text carefully before bidding to verify accuracy of description. If you don't see it in the pictures, it is not included.

Insurance is included in UPS shipping charges. Item shipped internationally on buyer's UPS, FEDEX or DHL accounts only.

We will accept payment for this item by company check, cashier’s check and wire transfer only.

If you have zero feedback, contact us prior to purchase so we know you are a serious bidder. Otherwise, we may cancel your bid before the auction closes. It should be obvious that you should only bid if you are serious and do intend to complete the transaction. Any stated warranty will be voided if the unit is opened or if any calibration or lockout stickers have been tampered with or removed.

Please note that shipping and insurance costs are non-refundable.

Our feedback is very important to us and we strive for 100% positive on every transaction. If you are unsatisfied with any aspect of your transaction, please contact us before leaving negative or neutral feedback so that we can address and remedy the issue immediately. Additionally, we are always happy to leave positive feedback for our trading partners after a successful transaction.

Make sure that you check out our other auctions for more great deals on test and measurement equipment.

                                                  Thank you and good luck bidding.
