You are bidding on a Rohde & Schwarz FSU26 20 Hz - 26.5 GHz Spectrum Analyzer with Options K5 (Application firmware GSM/EDGE tests for FSP, FSU, FSQ), K72 (Application firmware 3GPP-FDD BTS transmitter test for FSMR, FSP, FSU, FSQ) and K74 (3GPP HSDPA base station test application firmware for FSMR, FSU, FSP, FSQ). This unit will come with a fresh calibration performed prior to shipment! To handle the wide variety of measurement tasks in product development, an instrument must offer ample functionality and excellent performance in all areas of interest. The R&S FSU fully meets these requirements. Its wide dynamic range makes the R&S FSU an ideal tool for base station development and testing. That plus the excellent characteristics already incorporated in the standard model, e.g. < 0.3 dB total measurement uncertainty, gated sweep and IF power trigger. THIS UNIT IS CURRENTLY SOLD BY ROHDE AND SCHWARZ FOR OVER 80K!

Features:

Frequency Range - 20 Hz to 26.5 GHz

DANL- -158dBm (1 Hz RBW)

Phase Noise (Typ.) - -133 dBc @ 10 KHz offset (1 Hz RBW)

TOI (Typ.) +25 dBm

Resolution Bandwidth - 1 Hz to 50 MHz

DANL with Preamplifier option B24: typ. -168 dBm (1Hz RBW) @ 20 GHz

Fast ACP in time domain

Up to 70 measurements per second(including trace transfer via GPIB)

Measurement routines for TOI, MC ACP(R), OBW, CCDF, APD, etc. as standard

Application firmware available for GSM/EDGE, Bluetooth, WCDMA/ HSPDA/ TD-SCDMA, CDMA-2000/ 1xEV-DV/ 1xEV-D0, etc.

You can view the specs for this unit here: Product Specs
